Elatest – Quick method for measuring rubber density

Automatic determination of the density by means of sample weight and volume

The Elatest® determines the density of polymers, in particular of rubber and unvulcanized rubber compounds – a decisive importance for rubber processing, both during recipe development and for continuous production control.

The sample material is compressed in the measuring cylinder. Any gas contained in the sample escapes during this compression process. Under a preset pressure, the moving piston reaches a position which is specific for each individual sample, i.e. the sample is compressed to its specific volume. The stroke of the piston is measured by a displacement transducer and transmitted to the computer.

From the sample weight and volume, the computer automatically calculates the density. The software of the implemented computer is user-friendly and is operated via a touchscreen. Excellent reproducibility of the measured values, easy handling, and the reliability make the Elatest® best suited for both, for production control and for research and development.

Fields of application:
• Rubber industry
• Tire manufacturers
•Cable industry

Brochures

This browser does not support PDFs. Please download the PDF to view it: Download PDF.

Videos

Jessica Wiertz shows the Brabender Elatest which determines the density of rubber and non-vulcanized rubber compounds, based on the weight and the volume of the compressed sample. The density of the sample is of decisive importance for rubber processing both during recipe development and for continuous production control.
